Model Name |
CA-NP848N3EA-TA-2812PW |
|
Camera |
|
|
Imaging Device |
1/2.7” |
|
Effective Pixels |
4K 3840×2160 (EA) |
|
Scanning System |
Progressive CMOS |
|
Min. Illumination |
Color 0.002Lux @(F1.2,AGC ON); B/W 0 lux @ IR ON |
|
Lens |
|
|
Focal Length (Zoom Ratio) |
4x Optical Zoom (2.8-12mm) |
|
Max. Aperture Ratio |
F1.6 |
|
Angular Field of View |
Horizontal 113° ~ 31.4°, Vertical 58.4° ~ 17.6° , Diagonal 138.6° to 36° |
|
Operational |
|
|
IR LED |
4pcs |
|
Red & Blue Light |
2pcs (1Red & 1Blue) |
|
IR Viewable Length |
Up to 50m |
|
Type of complementary light |
Switchable infrared light |
|
Pan Range |
0°~ 355° |
|
Pan Speed |
Configurable from 0.6° to 54°/s |
|
Tilt Range |
0°~ 90° |
|
Tilt Speed |
configurable from 0.6° to 54°/s |
|
Preset |
255 |
|
Preset Speed |
Max. 60°/sec |
|
Enforcer Light |
Support |
|
Motion Detection |
Off/On (8 Level) |
|
Wide Dynamic Range |
DWDR |
|
Image Enhancement |
BLC, 3D DNR, HLC |
|
Day & Night |
Day&Night Mode |
|
Image Setting |
Rotation Mode, Saturation, Brightness, Contrast, Sharpness, White Balance |
|
Electronic Shutter Speed |
1/5 ~ 1/20000s |
|
On-Board Storage |
Micro SD slot, up to 256GB |
|
Audio |
Built-in Microphone & Speaker |
|
Hardware Reset |
Yes |
|
Smart Features |
Face Detection, Human & Vehicle Detection, Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density, Queue Length, License Plate,Rare Sound, Intrusion, Region Entrance, Region Exiting. |
|
Network |
|
|
Ethernet |
RJ45(10/100BASE-T) |
|
Video Compression Format |
H.265/H.265+/H.264/H.264+/MJPEG |
|
Resolution |
8MP(3840×2160)@30fps |
|
Video Quality Adjustment |
256Kbps ~ 16Mbps |
|
Bitrate control method |
CBR/VBR |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
|
Security |
IP address filter;complicated password;Authenticated username and password |
|
Interface Protocol |
ONVIF( Profile S/G/T/M) |
|
General |
|
|
Operating Temperature |
-20°C ~ +60°C ( −4°F ~ 140 °F) |
|
Operating Humidity |
≤ 90% RH |
|
Ingress Protection |
IP66 |
|
Power |
DC 12V/PoE |
|
Housing |
Metal |
