Model Name |
CA-NP842N4D25-AP |
|
Camera |
|
|
Imaging Device |
1/2.8” |
|
Effective Pixels |
8MP 3480(H)x2160(V) |
|
Scanning System |
Progressive CMOS |
|
Min. Illumination |
Color: 0.007 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
|
Lens |
|
|
Focal Length (Zoom Ratio) |
25x Optical Zoom (5 mm–125 mm) |
|
Max. Aperture Ratio |
F1.6 |
|
Angular Field of View |
Horizontal: 57 .6° to 2.9° Vertical: 33.2° to 1.6°, Diagonal: 65.2° to 3.3° |
|
Operational |
|
|
IR LED |
6pcs |
|
IR Viewable Length |
Up to 100m |
|
Type of complementary light |
Switchable infrared light |
|
Pan Range |
360° |
|
Pan Speed |
Configurable from 0.6° to 80°/s; preset speed: 120°/s |
|
Tilt Range |
-10° to 90° (Auto Flip) |
|
Tilt Speed |
Configurable from 0.6° to 80°/s, preset speed 100°/s |
|
Preset |
255 |
|
Preset Speed |
Max. 60°/sec |
|
Tour |
Support |
|
Patrol Scan |
1 Scan |
|
Pattern Scan |
4 Pattern |
|
Motion Detection |
Off/On (8 Level) |
|
Wide Dynamic Range |
120dB |
|
Image Enhancement |
BLC, 3D DNR, HLC |
|
Day & Night |
Day&Night Mode |
|
Image Setting |
Rotation Mode, Saturation, Brightness, Contrast, Sharpness, White Balance |
|
Electronic Shutter Speed |
1/5 ~ 1/20000s |
|
On-Board Storage |
Micro SD slot, up to 256GB |
|
Audio |
1 Input, 1 Output |
|
Alarm I/O |
1 Input, 1 Output |
|
Hardware Reset |
Yes |
|
Smart Features |
Face Detection, Human & Vehicle Detection, Auto Tracking, Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density, Queue Length, License Plate,Rare Sound, Intrusion, Region Entrance, Region Exiting. |
|
Network |
|
|
Ethernet |
RJ45(10/100BASE-T) |
|
Video Compression Format |
H.265/H.265+/H.264/H.264+/MJPEG |
|
Resolution |
8MP(3840×2160)@30fps |
|
Video Quality Adjustment |
256Kbps ~ 16Mbps |
|
Bitrate control method |
CBR/VBR |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
|
Security |
IP address filter;complicated password;Authenticated username and password |
|
Interface Protocol |
ONVIF( Profile S/G/T/M) |
|
General |
|
|
Operating Temperature |
-30 °C to 60 °C (-22 °F to 149 °F) |
|
Operating Humidity |
≤ 90% RH |
|
Ingress Protection |
IP67, IK10 |
|
Power |
DC 12V/PoE+, max. 22 W |
|
Housing |
Metal |
