Model Name |
CA-NP4121N6FEE-A20PW |
|
Camera |
|
|
Imaging Device |
1/1.6” |
|
Effective Pixels |
12MP 3536(H)×3536(V) |
|
Scanning System |
Progressive CMOS |
|
Min. Illumination |
Color 0.009 Lux @ F1.6(AGC ON); B/W 0 lux @ IR ON |
|
Lens |
|
|
Focal Length (Zoom Ratio) |
2.0mm |
|
Max. Aperture Ratio |
F2.8 |
|
Angular Field of View |
Horizontal FOV 180°(wall mount), 360°(ceiling mount) |
|
Min. Object Distance |
0.4m |
|
Lens Type |
Fixed(M12) |
|
Operational |
|
|
IR LED |
3pc |
|
IR Viewable Length |
Up to 10m |
|
Type of complementary light |
Default warm light, Switchable infrared light |
|
Motion Detection |
Off/On (8 Level) |
|
Wide Dynamic Range |
WDR |
|
Image Enhancement |
BLC, 3D DNR, HLC |
|
Day & Night |
IR cut filter with auto switch(Day/Night/Image/Schedule) |
|
Image Setting |
Rotation Mode, Saturation, Brightness, Contrast, Sharpness, White Balance |
|
Electronic Shutter Speed |
1/5 ~ 1/20000s |
|
On-Board Storage |
Micro SD slot, up to 256GB |
|
Alarm I/O |
NA |
|
Audio |
Built-in Microphone & Speaker |
|
Mount Type |
Ceiling/Metope/Desktop mounting |
|
Decoding Mode |
Hardware decoding and software decoding |
|
Hardware Reset |
Yes |
|
Display Mode |
Software Decoding: Hardware Decoding: |
|
AI Features |
Line Crossing, Crossing Counting, Heat Map, Rare Sound, Intrusion, Region Entrance, Region Exiting, Queue Length, Crowd Density |
|
Network |
|
|
Ethernet |
RJ45(10/100BASE-T) |
|
Video Compression Format |
H.265/H.265+/H.264/H.264+/MJPEG |
|
Resolution |
12MP(3536×3536)@30fps |
|
Video Quality Adjustment |
256Kbps ~ 16Mbps |
|
Bitrate control method |
CBR/VBR |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
|
Interface Protocol |
ONVIF( Profile S/G/T/M) |
|
General |
|
|
Operating Temperature |
-35°C ~ +60°C ( −31°F ~ 140 °F) |
|
Operating Humidity |
≤ 90% RH |
|
Ingress Protection |
IP67 |
|
Power |
DC12V: Max.7 .97W, PoE: Max.9.66W |
|
Housing |
Metal |
