Model Name |
CA-NP342M7KCI-HALTF-LF28PW |
|
Camera |
|
|
Imaging Device |
1/2.7” |
|
Effective Pixels |
8MP 3840(H)×2160(V) |
|
Scanning System |
Progressive CMOS |
|
Min. Illumination |
Color 0.007lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON |
|
Lens |
|
|
Focal Length (Zoom Ratio) |
2.8mm |
|
Max. Aperture Ratio |
F1.0 |
|
Angular Field of View |
Horizontal: 110°, Vertical: 58°, Diagonal: 131° |
|
Min. Object Distance |
2m |
|
Lens Type |
Fixed(M12) |
|
Operational |
|
|
IR LED |
1pc |
|
WarmLight |
2pcs |
|
Red & Blue Light |
2pcs (1Red & 1Blue) |
|
IR Viewable Length |
Up to 25m |
|
WarmLight Viewable Length |
Up to 20m |
|
Type of complementary light |
Default warm light, Switchable infrared light |
|
Motion Detection |
Off/On (8 Level) |
|
Wide Dynamic Range |
DWDR |
|
Image Enhancement |
BLC, 3D DNR, HLC |
|
Day & Night |
Full Color Mode /Day&Night Mode/ Smart IIIumination |
|
Image Setting |
Rotation Mode, Saturation, Brightness, Contrast, Sharpness, White Balance |
|
Electronic Shutter Speed |
1/5 ~ 1/20000s |
|
On-Board Storage |
Micro SD slot, up to 256GB |
|
Alarm I/O |
NA |
|
Audio |
Built-in Microphone & Speaker |
|
P2P |
Yes |
|
Hardware Reset |
Yes |
|
Smart Features |
Face Detection, Human & Vehicle Detection, Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density, Queue Length, License Plate,Rare Sound, Intrusion, Region Entrance, Region Exiting |
|
Network |
|
|
Ethernet |
RJ45(10/100BASE-T) |
|
Video Compression Format |
H.265/H.265+/H.264/H.264+/MJPEG |
|
Resolution |
Main Stream@20fps 8MP(3840×2160),5MP(2592×1944,3072×1728), 4MP(2592×1520),3MP(2304×1296),1080P(1920×1080), 960P(1280*960),720P(1280×720) |
|
Video Quality Adjustment |
256Kbps ~ 16Mbps |
|
Bitrate control method |
CBR/VBR |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
|
Security |
IP address filter;complicated password;Authenticated username and password |
|
Interface Protocol |
ONVIF( Profile S/G/T/M) |
|
General |
|
|
Operating Temperature |
-35°C ~ +60°C ( −31°F ~ 140 °F) |
|
Operating Humidity |
≤ 90% RH |
|
Ingress Protection |
IP67 |
|
Power |
DC12V: max.5.8W, PoE: max.7.1W |
|
Housing |
Metal |
