Model Name |
CA-NP248M6NM-HLDF-LFWA0832PW |
|
Camera |
|
|
Imaging Device |
1/1.8” |
|
Effective Pixels |
8MP 3840(H)×2160(V) |
|
Scanning System |
Progressive CMOS |
|
Min. Illumination |
Color: 0.0008 Lux @ (F1.7, AGC ON);0 Lux with IR |
|
Lens |
|
|
Focal Length (Zoom Ratio) |
(8-32mm) Fast Zoom |
|
Max. Aperture Ratio |
F1.7 to F 1.76 |
|
Angular Field of View |
H:40(W)-14(T)° V:27(W)-10(T)° D:49(W)-17(T)° |
|
Min. Object Distance |
W:1.5 m ~ INF, T:2.5 m ~ INF |
|
Iris Type |
Precise Iris |
|
Lens Type |
Motorized Zoom |
|
Operational |
|
|
IR LED |
8 |
|
WarmLight |
4 |
|
IR Viewable Length |
Up to 100m |
|
WarmLight Viewable Length |
Up to 30m |
|
Type of Complementary Light |
Default Warm Light, Switchable Infrared Light |
|
Motion Detection |
Off/On (8 Level) |
|
Wide Dynamic Range |
120dB WDR |
|
Image Enhancement |
BLC, 3D DNR, HLC |
|
Day & Night |
Full Color Mode/Day&Night Mode/Smart IIIumination |
|
Image Setting |
Rotation Mode, Saturation, Brightness, Contrast, Sharpness, White Balance |
|
Electronic Shutter Speed |
1/5 ~ 1/20000s |
|
On-Board Storage |
Micro SD slot, up to 256GB |
|
Alarm I/O |
2 Input, 2 Output |
|
Audio |
1 input (RCA), 1 output (RCA), Built-in Microphone |
|
Custom Voice |
Yes |
|
Hardware Reset |
Yes |
|
LPR Vehicle Speed |
Up to 120 Km/h |
|
Smart Features |
License Plate, Human & Vehicle Detection, Line Crossing, Object Detection, Crossing Counting, Face Recognition, Heat Map, Crowd Density, Queue Length, Rare Sound,Intrusion, Region Entrance, Region Exiting. |
|
Network |
|
|
Ethernet |
RJ45(10/100BASE-T) |
|
Video Compression Format |
H.265/H.265+/H.264/H.264+/MJPEG |
|
Resolution |
8MP(3840×2160)@30fps |
|
Video Quality Adjustment |
256Kbps ~ 16Mbps |
|
Bitrate control method |
CBR/VBR |
|
Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
|
Security |
IP address filter;complicated password;Authenticated username and password |
|
Interface Protocol |
ONVIF( Profile S/G/T/M) |
|
General |
|
|
Operating Temperature |
-35°C ~ +60°C ( −31°F ~ 140 °F) |
|
Operating Humidity |
≤ 90% RH |
|
Ingress Protection |
IP67, IK10, NEMA 4X |
|
Power |
DC12V: Max 10.24W, POE(48V): Max 12.28W |
|
Housing |
Metal |
