Model Name |
CA-N10128OD-E4HL |
|
|
Video |
||
|
IP Camera |
Resolution |
12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P) |
|
IP Video Input |
128-Channel |
|
|
Recording |
Incoming |
1024Mbps |
|
Outgoring |
800Mbps |
|
|
Performance |
||
|
Live/Playback |
Compression |
Audio: G.711a |
|
Frame rate |
12MP: 90fps 8MP: 360fps 4MP: 720fps 2MP: 1440fps; |
|
|
Event |
MD(Sensitivity Level 1~8) |
|
|
Video loss |
||
|
Beep, Email, |
||
|
Playback function |
Fast forward / backward (2x, 4x, 8x,16x) |
|
|
Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
||
|
Playback |
Max 16CH Playback |
|
|
Voice Command |
Home Device: Google Assistant, Amazon Alexa |
|
|
Fisheye |
Support Dewarp |
|
|
Network |
Protocal |
ARP; DDNS; DHCP; DNS; Easy DDNS; HTTP; ICMP; IGMP; IPv4; IPv6; NTP; RTCP; RTP; RTSP; SSH; TCP/IP;UDP; Unicast; UPnP |
|
WEB |
IE10/11 |
|
|
Mobile viewer |
Yes |
|
|
Push Notification |
P2P |
|
|
Interface |
||
|
P/W Reset |
YES |
|
|
Monitors |
VGA |
1-Port (1024*768, 1280*720, 1280*1024, 1440*900) |
|
HDMI 1 |
3 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/7680*4320/EDID)Async out |
|
|
HDMI 2 |
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 /EDID) Async out |
|
|
Connections |
PoE |
N/A |
|
Ethernet |
2 RJ45 100/1000 Base-T |
|
|
USB |
USB2.0*1(front); USB3.0*2(rear) |
|
|
RAID |
RAID0, RAID1, RAID5, RAID6, RAID10 |
|
|
HDD |
16 SATA HDD, up to 18TB (Enterprise-Class) |
|
|
E-SATA |
1 |
|
|
Audio |
1 Input(RCA), 1 Output (RCA) |
|
|
Alarm |
16 Input / 4 Output |
|
|
RS-485 |
1 |
|
|
AI Features |
||
|
|
Smart Motion |
SMD |
|
Perimeter intrusion, Line Crossing, Object Detection, Pedestrian & Vehicle Detection, Face Detection, Cross Counting, Sound Detection, Video Tampering, Cross Counting, intrusion, Enter Region, Exit Region, Schedule |
||
|
Alarm |
||
|
General Alarm |
Motion Detection, PIR, Combined Alarm, PTZ Linkage, Alarm Schedule, Deterrence, Siren, Alarm Disarm |
|
|
Exceptions Alarm |
HDD Full, Disk Error, Video Loss |
|
|
General |
||
|
System |
OS |
Embedded Linux |
|
OSD Language |
English/French/Spanish/Portuguese/German/Italian/Greek/Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/Arabic/Korean/Japanese/Thai/Hindi/Romanian/Dutch/Polish |
|
|
Third-party |
RS API/Onvif (profile S/G/T) |
|
|
Installation wizard |
Yes |
|
|
Mechanical Design |
Dimension (WxDxH) |
440*460*149mm |
|
Electrical |
Input Voltage/ |
250W |
|
Power consumption (excluding hard disk) |
8W |
|
|
Environmental |
Operating Temperature/Humidity |
Temperature: -10°C~+50°C (14°F ~ 122°F) |
